Material: Sapphire
Diameter Tolerance: +/-0.15 mm
Thickness Tolerance: +/-0.1mm
Parallelism: <3 arc minutes
Surface Quality: 60-40
Surface Figure: λ/10@633nm
Bevel: 0.25mm×45 °
Clear Aperture: 90%
Coating: Specified by customers
Sapphire crystal is the hardest oxide crystal, is the basic single crystal form of aluminum oxide (Al2O3). It has a series of excellent physical and chemical characteristics such as high strength, high hardness, high temperature resistance,abrasion resistance, corrosion resistance, good light transmission performance and excellent electrical insulation performance. Therefore, it can be widely used in various demanding fields such as national defense, scientific research, and civil industry.
Sapphire is frequently used in optical windows,optical spherical lenses, and other optical components. Additionally, sapphire is often used in high-powered lasers due to its ability and durability to withstand high temperatures. If you need an optical material that can stand up to the most demanding applications, Yutai Optics highly recommend optical grade sapphire for you.
